pH Transmitter BPHT754

The BPHT754 is a reliable isolated pH/ORP transmitter enclosed in a small DIN-rail mounting housing especially designed for, industrial and water applications.

Categories: ,

Description

The BPHT754 is a reliable isolated pH/ORP transmitter enclosed in a small DIN-rail mounting housing especially designed for, industrial and water applications. BPHT754 provides linear current or voltage output and relay alarm/control output as well. The device is equipped with additional Pt1000 input for automatic temperature compensation. All the transmittercontroller parameters are user-programmable via RS232 interface and free configuration software. They include: preset pH/ORP ranges, analog output range and direction, relay setpoint and hysteresis and direction, temperature compensation parameters, etc. Due to its wide range, flexibility, programmability and reliability, BPHT754 transmitter is very suitable for water treatment and processing applications in food, pharmaceutical and many other industries. The BPHT754 is available with a wide choice of electrodes to suit the installation and the chemical medium

Title Type Size
BPHT754 application/pdf 632 KB
